Long Range 61.1 kWh total (57.4 kWh usable)
| Nominal voltage | 355 V |
|---|---|
| Operating range | 310–404 V* |
| Protocol | CAN bus (500 kbps), SAIC/MG EV-CAN. |
| Home use (V2H) | Supported via Battery-Emulator (stationary home storage)* |
| Cooling | liquid |
| Battery-Emulator support | · GitHub |
| Built-in contactors | Yes (source) |
| Dimensions | Not confirmed |
|---|---|
| Weight | 410 kg |
| Cell configuration | 96s |
| Connector | CCS Combo 2 |
| Connectors | CCS Combo 2 on donor car; Amphenol HV connector on enclosure. |
| Used | from £1,395 5 |
|---|
* Data sourced from dalathegreat/Battery-Emulator firmware driver specifications and the Battery-Emulator Wiki.
Live eBay UK listings, fetched 25 October 2026. Prices and availability change.
96s CATL prismatic cell arrangement. SAIC/MG BMS communicates on dedicated 500 kbps CAN bus. Battery-Emulator handles contactor precharge sequencing and state-of-charge tracking.
CATL NMC prismatic cells configured as 96s. Shared with Roewe Ei5 and MG Marvel R. Operating voltage window 310.0–404.0 V*. Standard 400 V class architecture matches common solar hybrid inverters (Solis, Deye, SolaX, GoodWe).
Internal contactors lock out permanently if BMS records crash data or sustained high-voltage isolation fault below 100 kΩ.
