84 kWh (2026 US spec; also Australia sheet)
| Nominal voltage | 697 V |
|---|---|
| Operating range | 566.4–806.4 V* |
| Protocol | C-CAN / E-GMP Powertrain CAN (500 kbps), Mobis BMS. Transmits 0x153, 0x154, 0x451, 0x542*. |
| Home use (V2H) | V2L only |
| Cooling | liquid |
| Battery-Emulator support | Testing ongoing · GitHub |
| Built-in contactors | Yes (source) |
| Dimensions | Not confirmed |
|---|---|
| Weight | Not confirmed |
| Cell configuration | 192s2p |
| Connector | NACS on 2026 US DC; CCS adapter listed |
| Connectors | 2026 US: NACS DC and CCS adapter. V2L 3.6 kW. |
| Used | from £3,499 4 |
|---|
* Data sourced from dalathegreat/Battery-Emulator firmware driver specifications and the Battery-Emulator Wiki.
Live eBay UK listings, fetched 25 October 2026. Prices and availability change.
Higher-voltage liquid-cooled pack. Export documented as V2L only.
84 kWh, 697 V, liquid-cooled on the Australia sheet, V2L 3.6 kW. Other structural fields not confirmed. Same warranty note as the 63 kWh row. Used bulk price not confirmed.
26V432's six cars are 2023-2024 and not identified as only one pack size.
